Wall Cladding

Metal wall and soffit panels.

Three steel panel profiles for walls, soffits and canopies — made to length up to 52' in 16 finishes. Pickup in Croydon, PA or delivery across the region.

Request Panel Pricing Compare panels

Wall and soffit panel in charcoal showing 10 to 24 inch coverage, 1 inch rib height and lengths up to 40 feet

Concealed fastener

Wall & Soffit Panel

Flush, clean lines with your choice of reveal.

A 1" flush panel that interlocks for fast installs and hides every fastener. Pick the gap between panels — or mix reveals for a custom look. Vented option for soffits.

Coverage: 10" or 24"
Rib height: 1"
Lengths: 2' – 40'

Reveal options: None, ½", 1", 2" or 3" — mix and match
Gauge: 24 & 26 ga steel
Fasteners: Concealed · interlocking
Install: Vertical wall or soffit · solid or vented
Finish: SMP paint over Galvalume® steel · 40-year limited finish warranty
Trim: Color-matched standard trim available

Best for

Soffits (vented or solid)
Flush wall cladding
Fascia
Residential & commercial

Request pricing See colors

Exposed fastener

PBR Panel (R-Panel)

The go-to structural panel for walls and roofs.

A 36" coverage workhorse with 1¼" trapezoidal ribs on 12" centers and a purlin-bearing leg for a stronger lap. Covers big walls fast and runs up to 52' long.

Coverage: 36"
Rib height: 1¼"
Lengths: 1' – 52'

Rib spacing: 12" on center
Gauge: 24 & 26 ga steel
Fasteners: Exposed · purlin-bearing leg
Install: Vertical or horizontal · open framing or solid deck
Roof slope: 1:12 minimum (with sealant)
Finish: SMP paint over Galvalume® steel · 40-year limited finish warranty
Trim: Color-matched standard trim available · die-formed ridge cap

Best for

Pole barns & garages
Agricultural buildings
Commercial & industrial
Walls and roofs

Request pricing See colors

Exposed fastener

5.25 Panel

Bold, symmetrical ribs that span and cantilever.

A 31½" coverage panel with 1¼" symmetrical ribs on 5¼" centers. Strong spans make it ideal for carports and canopies — and run horizontally, it makes a striking accent wall.

Coverage: 31½"
Rib height: 1¼"
Lengths: 1' – 52'

Rib spacing: 5¼" on center · symmetrical (no lap direction)
Gauge: 24 & 26 ga steel
Fasteners: Exposed
Install: Vertical or horizontal
Finish: SMP paint over Galvalume® steel · 40-year limited finish warranty
Trim: Color-matched standard trim available

Best for

Carports & walkway canopies
Horizontal accent walls
Commercial walls
Industrial roofing

Request pricing See colors

Which panel?

Compare at a glance.

Not sure which profile fits the job? Start here — or send us your plans and we'll recommend one.

	Wall & Soffit Panel	PBR Panel (R-Panel)	5.25 Panel
Choose it when	You want a smooth, modern face with no exposed screws.	You need the most coverage per sheet at the best price.	You want strong spans or a bold horizontal rib line.
Fasteners	Concealed fastener	Exposed fastener	Exposed fastener
Coverage	10" or 24"	36"	31½"
Rib height	1"	1¼"	1¼"
Lengths	2' – 40'	1' – 52'	1' – 52'
Best for	Soffits (vented or solid) · Flush wall cladding	Pole barns & garages · Agricultural buildings	Carports & walkway canopies · Horizontal accent walls

Before you order

Cut to length
Give us a cut list by length and quantity — panels arrive ready to hang.
Order panels and trim together
One order keeps everything from the same coil run, so colors match.
Confirm color with a chip
Screens vary. Ask for a physical sample before you commit.
Near the shore?
Choose a painted finish — bare Galvalume® is not recommended within 1,500' of salt water.
